7.6 Sensors
Fill level sensor
The fill level sensor reacts when it is no longer covered with seed.
Its height can be adjusted according to the desired quantity in the
hopper when the sensor is triggered.
The intensity of the sensor can also be adjusted for the respective
seed type. It is adjusted using the small slotted screw at the rear of
the sensor.
When the sensor is switched, it lights up and the hopper is full.
You can cover the sensor at the front with your hand and it should
then light up.
This makes it easy to check whether the sensor is working and if
the intensity is correct.
7.7 Adjusting the hopper cover
If air escapes between the hopper and the
cover, it is possible that the fastener is not
adjusted correctly.
In this case, the fastener must be adjusted
such that the seal that on the hopper presses
against the cover again, so that on the one
hand, the system is sealed and on the other,
the fastener is still easy to open and close.
To adjust the fastener, you only have to
loosen the lock nut (1), and then screw in the
ring bolt (2) a little (see Fig.: 33). Then
tighten the lock nut again, ensuring that the
ring bolt is in the correct position. Make sure
that the two fasteners are tensioned evenly,
i.e., that the two ring bolts are screwed in to
the same depth in the turning part of the
fastener.
Fig.: 32
