Aqua Computer QUADRO User Manual

QUADRO
unlimited number of data sources to each export data set, the total number of ex-
port data sets is also unlimited.
9.
9.9.
9. Sensor configuration
Sensor configurationSensor configuration
Sensor configuration
Select “Sensors” from the device list below the “QUADRO” entry. In the
upper area, the thirteen available sensors are displayed including current
data. In the lower area, the currently selected sensor can be configured.
9.1.
9.1.9.1.
9.1. Hardware temperature sensor
Hardware temperature sensor Hardware temperature sensor
Hardware temperature sensor
The first four sensors in the list represent the temperature sensor inputs of the
QUADRO.
If necessary, each temperature sensor can be calibrated by adding an offset of
±15 °C.
9.2.
9.2.9.2.
9.2. Hardware flow sensor
Hardware flow sensorHardware flow sensor
Hardware flow sensor
The fifth sensor in the list represents the flow sensor input of the QUADRO. Cali-
bration values for sensors sold by Aqua Computer can conveniently be selected
from a drop-down list. Select the appropriate entry for the flow sensor connected
to the QUADRO.
If necessary, the flow rate can be calibrated by ±10 %.
9.3.
9.3.9.3.
9.3. Software sensors
Software sensorsSoftware sensors
Software sensors
The last eight sensors in the list are software sensors and can be used to transmit
sensor data that is not physically available to the QUADRO controller from the
computer by USB connection.
During installation of the aquasuite, the background service “Aqua Computer Ser-
vice” is also installed. This service supplies various data from PC components and
imported data from aquasuite web, additionally sensor data provided by third par-
ty software can be accessed. In order to access third party software data, the third
party software has to be correctly installed, configured and running.
Currently, the “Aqua Computer Service” supports data transfer from “HWiNFO”
(REALiX, Freeware, www.hwinfo.com) and “AIDA64” (FinalWire Ltd., subject to li-
cense fees, www.aida64.com).
HWiNFO automatically exports all sensor values, the “Sensor Status” Window has
to be open.
In the AIDA64 preferences menu, writing to WMI must be activated in the „external
applications“ sub-menu:
- 14 - Aqua Computer GmbH & Co. KG © 2018-2020
Gelliehäuser Str. 1, 37130 Gleichen
