Simpool pH model INSTRUCTION AND MAINTENANCE MANUAL
Programmable digital peristaltic pump ENGLISH
ADSP7000407 rev. 1.2 27/03/2015 43/313
1.3 TECHNICAL FEATURES
1.3.1 ELECTRICAL FEATURES
For the power supply value we recommend reading the label on the pump!
1.3.2 PERFORMANCE
Maximum height of the suction tube: 1.5 m
Flow rate and backpressure: refer to the table below and read the label in the pump to identify the
corresponding model.
Operating ambient temperature: 0 ÷ 45°C
Transport and Packaging Temperature: -10 ÷ 50°C
Protection rating: IP65
2.0 INSTALLATION
2.1 GENERAL RULES
Pump installation must be carried out as follows:
In vertical position with an uncertainty not greater than +/-15°.
Away from sources of heat in dry locations, at a maximum temperature of 40°C and a minimum of 0°C.
In a ventilated environment and easily accessible to an operator for periodic maintenance.
Above the level of the liquid that needs to be dosed, at a height of 1.5 metres maximum.
Do not install the pump above the tank when using liquids that emit fumes, unless it is sealed shut.
2.2 INSTALLATION KIT
When you purchase the pump, it includes everything required for correct installation, specifically:
Bracket (code ADSP8000025);
Plugs and screws (cod. ADSP6000041);
pH 4.01 buffer solution (cod. ADSPH4);
pH 7.00 buffer solution (code ADSPH7);
Empty bottle to wash the pH probe (code ADSP4000020);
PT100 temperature probe with 3 wires (optional, code ADSTS100N);
Level Probe (optional, code ADSLG4);
Foot strainer (*);
2-in-1 injection probe-holder (code ADSP6000880);
PVC suction and delivery tubes (*);
pH electrode with 5 m cable (code ADELTPH055);
O-rings and spacers, ring nut for the pH electrode (*);
Drill bit Ø 24 (*);
(*) Kit components included in the ADSP6000631 code
