Diverter Controller Matrix
The controller will automatically assign the
outlets as follows:
• Top button to outlet A of the diverter
• Bottom button to outlet B of the diverter
If using a wired remote
By default the remote button will assign outlet A as the primary. If required, this can be
changeed from outlet A to outlet B, meaning when operated via the wired remote, the
preferred outlet will always operate first.
Switch position 1 will allocate Outlet A as the primary.
Switch position 2 will allocate Outlet B as the primary.
Changing the switch position will not override the main controller settings.
Switch position 1 will allocate Outlet A as the primary.
Switch position 2 will allocate Outlet B as the primary.
Controller 1
Controller 2
Refer to User Instructions,
Configure Outlets section.
Controller 3
To Next Page
