Aqualisa SMART - Securing Cover Plate with Grub Screw; Attaching Shower Head to Fixed Arm; BATH OVERFLOW FILLER; Overflow Filler Suitability for Bath Thickness

Secure the cover plate to the arm using the grub screw
and 2.5mm hexagonal key provided.
10
Ensuring the rubber washer is in the correct position,
attach the shower head to the fixed arm and carefully
secure using a suitable spanner, or a tool with smooth
jaws, suciently to lock the head into position.
11
BATH OVERFLOW FILLER
Carefully unscrew and remove the overflow filler
outlet from the body assembly and set aside.
1
Installation videos are available on our website www.aqualisa.co.uk/installation-
videos or alternatively, scan the QR code on the reverse of this guide.
The bath overflow filler is suitable for baths up to a maximum thickness of 24mm.
