Aqualisa SMART - Securing Overflow Filler Outlet to Body; Connecting Flexible Hose to Inlet; Connecting Hose to Supply Pipe with Check Valve; WASTE PIPE EXTENSION KIT

PTFE thread tape MUST be used to guarantee
a watertight seal.
Ensuring the rubber washer is correctly aligned,
pass the overflow filler outlet through the bath and
secure to the body assembly.
7
Remove the relevant inlet blanking plug and attach the
flexible hose to the blended inlet connection.
8
Connect the flexible hose to the blended supply pipe ensuring a suitable non
restrictive double check valve (not supplied) is fitted in line with current Water
Supply Regulations.
9
WASTE PIPE EXTENSION KIT
If required for larger baths, a 900mm waste pipe conversion kit is available
from the Aqualisa Customer Service department, part number 910064. Please
contact our Customer Service Department on 01959 560010.
Unscrew the clamping nut and remove the waste pipe from the
waste assembly.
1
