9
www.araknisnetworks.com | Support: 866.838.5052
Example - 1
Example - 2
Figure 3. Single Switch Network
Figure 4. Multiple Switches in Network
Desktop
PC
Server
IP
Phone
Printer/
Scanner
AppleTV
Desktop
PC
Server
IP Camera
Printer/
Scanner
IP Surveillance
NVR
IP
Phone
AppleTV
2 | INSTALLATION
