3.18) Open the storage compartment lid and pull the
connector through into the storage compartment.
3.19) Prepare the (668PJ015) relay box by applying
the foam tape (668PB015) cut in half to the
underside of the box as shown.
3.20) With 2 off 200mm long cable ties, tie off the relay
box to the hole in the sheetmetal panel in the
storage compartment. Connect the connectors
and wrap the second piece of foam tape around
them to aid in the prevention of rattling noise.
