OEM 2019 MR TRITON BED LINER PART NUMBER: MZ330745TB
6.22) Prise the rear of the bed liner away from the car
to dislodge the double sided taped brackets
holding the rear of the liner to the vehicle’s tub
and remove the liner and any double sided tape
holding the rear of the bed liner.
6.23) At the front LH Front corner of the bed liner
mark out and trim using a jig saw and sand the
cut edge.
Repeat in mirror image on the opposite side.
6.24) At the rear LH Corner of the bed liner mark out
and trim using a jig saw and sand the cut edge.
Repeat in mirror image on the opposite side.
Fit the bed liner to the car after steps in section
2 up to and including 2.26 have been
completed. Then fit the canopy Section 3 and 4
up to step 4.33.
