4 Installing the Air System
30
Push the airline into the compression fitting body and screw the
outer nut down onto it. Using a 12mm spanner, tighten the outer nut
onto the compression fitting body.
NOTE : Some force is required to crush the ferrule, however
the outer compression nut will tighten against a stop.
Over tightening will not create a better seal.
Secure any loose sections of tube with a cable tie.
NOTE : When right angle routing of the tube is not required,
screw the compression fitting body straight into the
bulkhead fitting body (Fig.21.).
