ARB AIRLOCKER RD136 - Itemized Parts List

7 Parts List
40
7.3 Itemized Parts List (See exploded diagram Figure 27.)
ITEM #
QTY
DESCRIPTION
PART #
NOTES
01
1
FLANGE CAP KIT
027314SP
02
1
BONDED SEAL
160703SP
03
04
1
CLUTCH GEAR & WAVESPRING KIT
050904SP
04
4
SHORT CROSS SHAFT
060403SP
05
4
PINION GEAR
SEE NOTE
3
06
4
PINION THRUST WASHER
SEE NOTE
4
07
1
SIDE GEAR
SEE NOTE
3
08
2
SIDE GEAR THRUST WASHER
SEE NOTE
4
09
1
COUNTERSUNK SCREW (PK OF 2)
200213SP
10
1
RETAINING PIN SET (PK OF 4)
120601SP
11
-
TAPERED ROLLER BEARING
NOT SUPPLIED
2
12
1
SEAL HOUSING RETAINING CLIP
150601SP
13
1
SEAL HOUSING KIT
081901SP
14
1
SEAL HOUSING O-RINGS (PK OF 2)
160207-2
1
15
1
ADJUSTER NUT
100102SP
16
1
WAVESPRING
150704SP
17
1
SPLINED SIDE GEAR
SEE NOTE
3
18
1
SPIDER BLOCK
070201SP
19
1
THRUST BLOCK
110502SP
20
1
DIFFERENTIAL CASE
013014SP
*
9
RING GEAR BOLT SPACERS
4581061
*
1
BULKHEAD FITTING KIT (BANJO TYPE)
170114
5
*
1
AIR LINE (6mm DIA X 6m LONG)
170314SP
5
*
1
SOLENOID VALVE (12V)
180103
*
1
SWITCH|FR OR RR LOCKER
180225
*
1
CABLE TIE (PK OF 25)
180305
*
1
OPERATING & SERVICE MANUAL
& SERVICE MANUAL
210200
*
1
INSTALLTION GUIDE
2102136
*
Not illustrated in exploded view
NOTES
1
For replacement O-rings use only BS136 Viton 75.
2
For replacement Bearing use Timken Bearing #32010X (ARB# 160116).
3
Available only as complete 6 gear set # 728H151
Refer to seal housing set-up tech note (Sec. 5.2).
Refer to pinion modification tech note (Sec. 5.6).
4
Available only as complete thrust washer kit #730H01
5
All diffs produced before serial #17070001 came with 5mm air connection system.
For information contact ARB.
Part No. 2102136
Revision 27/10/2020
