USER MANUAL ARC
LAST UPDATED: 6/01/2017 14
There are a lot of important steps and consider while mounting the front wheel.
To summarise the front motor assembly:
Install tyre and tube
Install disk brake rotor (if required)
Check washer positions are similar on both sides
Attempt to insert the motor into the drop outs.
If the motor does not t initially check what it is fouling on ( disk brake,
washer position or frame)
If the motor is fouling because of the washer position. Adjust washers
positions to create more/less space to t the motor. (if required)
If the motor is fouling because of the disk brake position. Adjust the brake
calliper to create more space (if required)
If the motor is fouling on a part of the bicycle frame. You may be doing
something incorrectly or the bicycle may be incompatible. Provide photos to
support for some help on the situation.
Once the motor has been mounted on forks, secure the motor by tightening
down the axle nuts. Ensure that washers are placed on the axle before
tightening the axle nuts.
Replace the rubber protectors for the axle nuts.
You have now completed the installation of the front motor.
Take each step slow and ensure that it ts before moving onto the next step. The
motor will rarely have to be forced into position and if mounted correctly, should
be rotating without rubbing on any part of the frame. Each bicycle is slightly
different to convert and will require some common sense to complete.
If you get stuck at any point or your are concerned, please contact support
through the manufacturer or retailer that you purchased from.
ASSEMBLY—FRONT MOTOR SUMMARY
