USER MANUAL ARC
LAST UPDATED: 6/01/2017 15
This will section show how to connect the battery and install it onto the
handlebars.
ASSEMBLY—BATTERY
Unwrap the packaging from battery. This a small pouch bag that holds the battery
and the motor controller. Looking at the top right picture, the bag has four plugs.
On the left side is the motor plug and the charger plug. On the right side is the
battery meter/throttle (green) and the pedal assistance plug (yellow). There are 3
straps that are available for mounting the pouch onto the handlebars.
Before mounting the battery onto the handlebars though it is likely that the battery
is physically disconnected inside the pouch for safe distribution. Locate the two
plugs that are pictures in the bottom two pictures and connect them together with
the arrows pointing towards each other. Once these are connected you can
reinsert the battery and motor controller back into the pouch.
