USER MANUAL ARC
LAST UPDATED: 6/01/2017 13
Now that the motor has been slotted in the front forks and can be rotated without
fouling on any of the frame/ brakes. The nal steps can be completed
ASSEMBLY—FRONT MOTOR
Insert washers on the axle on both sides to completely ll out the section so the
axle nut will have a nice at surface to tighten up to. Once the washers are in
place tighten the nuts up with a spanner/shifter.
Ensure that you check that you brake clipper is tightened up again. You can have
now completed the front motor installation. For the rest of the installation the
bicycle can be ipped back to its vertical position. Ensure that the tyres are nice
and pumped up before ipping over.
