To mount the PAS rst apply a single zip tie around the top section of the PAS.
This will allow you to partially test operation before mounting it more
permanently. The sensor should be no further than 5mm away from the magnet
wheel and not have a large angle.
ASSEMBLY—PEDAL ASSISTANCE
Now that the PAS is tted. When the system is turned on the and the pedals are
turned the motor will activate. You will notice that the light on the PAS will ash
when the system is operating. If this is not ashing you may nee to adjust the
sensors location/angle, so that the sensor is very close to the magnet wheel.
