E-10
Switching on
e front panel POWER button switches the unit on and
o.
e power light (next to the ‘A19 Integrated Amplier’
text) indicates the state of the amplier: it changes from
red to orange then green if mains power is connected
and the unit is switched on.
If the unit is le unused for an extended period of time
it will go into standby to reduce power consumption.
Press AUX & BALANCE to adjust the time of this
feature.
Display
e front panel DISPLAY button (or DISP on the remote
control) changes the display brightness between ‘on’,
‘dimmed’ and ‘o’. If the A19 is powered o with the
display brightness set to ‘o ’, the display resumes to
‘dimmed’ when the unit is powered on again.
Listening
Volume control
Use the control knob (or the +/– buttons on the remote)
to change the volume. Turn the knob clockwise to
increase the volume, anti-clockwise to reduce it.
Listening using headphones
e headphones socket (PHONES) accepts headphones
with an impedance rating between 8Ω and 2kΩ, tted
with a 3.5mm stereo jack plug.
e pre-amp outputs and speakers are muted when
headphones are plugged in and the front panel display
shows Headphone.
e headphones socket is always active, unless output
has been muted.
Muting output
e output of the A19 can be silenced by pressing MUTE
on the front panel (or
-
on the remote control). If the
unit is muted, the power light changes to orange and
the source is shown on the front display panel (e.g.
PVR MT).
Press
MUTE/
-
for a second time (or change the volume)
to cancel mute.
operation
AUX 31
AVPVRBDSATTUNERCDAUXPHONO
BALANCEDISPLAYMUTE
A19 INTEGRATED AMPLIFIER
AUX PHONES POWER
Selecting an audio source
e audio source may be selected from the front panel
(PHONO, AUX, CD, TUNER, SAT, BD, PVR or AV), or the remote
control (BD, PVR, TUN, AV, PHONO, AUX, CD or SAT).
In each case, the source is selected from the input
sockets with the corresponding name.
