Arcam A19 User Manual

E-12
Continuous power output (20Hz—20kHz at 0.5% THD), per channel
Both channels, 8Ω, 20Hz—20kHz 50W
Single channel, 4Ω, at 1kHz 90W
Harmonic distortion, 80% power, 8Ω at 1kHz 0.003%
Inputs
Phono (MM) cartridge:
Input sensitivity at 1kHz 5mV
Input impedance 47kΩ + 100pF
Frequency response (ref. RIAA curve) 20Hz—20kHz ± 1dB
Signal/noise ratio (Awtd) 50W, ref. 5mV input 80dB
Overload margin, 50mV at 1kHz 20dB
Line and AV inputs:
Nominal sensitivity 1V
Input impedance 10kΩ
Maximum input 4.6Vrms
Frequency response 20Hz—20kHz ± 0.2dB
Signal/noise ratio (Awtd) 50W, ref. 1V input 105dB
Preamplier output
Nominal output level 630mV
Output impedance 230Ω
Headphone output
Maximum output level into 600Ω 4V
Output impedance 1Ω
Load range 16Ω—2kΩ
Accessory power output
Using accessory power cable supplied, provides two
2.1mm DC connectors
6V, 1A
General
Mains voltage 110–120V~ or 220–240V~
Power consumption (maximum) 350W
Dimensions W x D x H (including feet) 432 x 275 x 85mm
Weight (net) 8.5kg
Weight (packed) 10.2kg
Supplied accessories Mains lead
CR108 remote control
2 x AAA batteries
Accessory power cable
E&OE
NOTE: All specication values are typical unless otherwise stated.
specications
Continual improvement policy
Arcam has a policy of continual improvement for its
products. is means that designs and specications
are subject to change without notice.

Arcam A19 Specifications

General

Output level	630 mV
Amplifier class	-
Frequency range	20 - 20000 Hz
RMS rated power	350 W
Output impedance	230 Ω
Input sensitivity	5 mV
Audio output channels	- channels
Peak power per channel	90 W
Signal-to-Noise Ratio (SNR)	80 dB
Total Harmonic Distortion (THD)	0.003 %
RMS power output per channel (8 Ohm)	50 W
Package weight	10200 g
Audio (L/R) out	7
Headphone outputs	1
Headphone connectivity	3.5 mm
Speakers connectivity type	Clamp terminals
Purpose	Home
Product color	Black
Connectivity technology	Wired
AC input voltage	110-240 V

Weight and Dimensions

Depth	275 mm
Width	432 mm
Height	85 mm
Weight	8500 g
