Arcam A70 User Manual

English
A70
E-11
Service information
Continual improvement policy
Arcam has a policy of continual improvement for its
products. This means that designs and specifications are
subject to change without notice.
NOTE: All specification values are typical unless
otherwise stated.
Sound cuts out unexpectedly
Before returning an amplifier for repair, please check the following:
Heatsink protection
If the temperature of the internal heatsink rises above a safe level, a thermal cutout inside the amplifier
operates, the power indicator on the front panel flashes and the protection system temporarily removes
power to the speakers. The system resets after the heatsink has cooled down. Note that because of
the high output voltage from a CD player, it is possible to drive the A70 at full power even though the
volume is not set at maximum.
Transformer protection
The transformer is separately protected against thermal overload damage which may occur in
exceptional circumstances. If the unit shuts down in this way, there is no indicator warning on the
front panel: we recommend you disconnect the power supply and wait 30 minutes for the amplifier to
completely cool. Power on in the normal way and the A70 will work normally.
Amplifier does not switch back on
The A70 and P90 amplifiers have a protection mechanism which is activated if you switch the unit on
immediately after turning it off. If this mechanism activates, wait 30 seconds before switching back on
again.
Technical specifications
Continuous power output, per channel
Both channels, 8Ω, 20Hz–20kHz 50W
Distortion, 8Ω, 80% power, 1kHz 0.005%
Inputs
Phono cartridge input sensitivity, MM 2.7mV
Line and tape inputs:
Nominal sensitivity
250mV
Input impedance
22kΩ
Signal/noise ratio (CCIR)
98dB
Preamplifier outputs
Nominal output level 545mV
Output impedance <50Ω
General
Power consumption (maximum) 450VA
Dimensions W x D x H (including feet) 430 x 330 x 85mm
Weight (net) 7.5kg
Weight (packed) 9.5kg
Supplied accessories mains lead
CR-389 remote control
2 x AAA batteries
E&OE

Arcam A70 Specifications

General

Amplifier class	-
Frequency range	20 - 20000 Hz
Output impedance	50 Ω
Audio output channels	- channels
Peak power per channel	50 W
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.005 %
Purpose	Home
On/off switch	Yes
Product color	Silver
Cables included	AC
Connectivity technology	Wired
Package weight	9500 g

Weight and Dimensions

Depth	330 mm
Width	430 mm
Height	85 mm
Weight	7500 g
