DIVISION II - OPERATION/MAINTENANCE
ATV Specifications
Specifications subject to change without notice.
ENGINE
Type Four-Cycle/Liquid Cooled
Bore x Stroke 98 mm x 85 mm (3.85 x 3.35 in.)
Displacement 641 cc (39 cu in.)
Spark Plug Type NGK CR6E
Spark Plug Gap 0.7-0.8 mm (0.028-0.032 in.)
Carburetor Type Keihin CVK36
Brake Type Hydraulic w/Brake Lever Lock and Auxiliary Brake
CHASSIS
Length (Overall) 215 cm (84.75 in.)
219.71 cm (86.5 in.) - Mud Pro
Height (Overall) 125 cm (49.3 in.)
131.45 cm (51.75 in.) - Mud Pro
Width (Overall) 120.7 cm (47.5 in.)
Suspension Travel (Front/Rear) 25.4 cm (10 in.)
Tire Size (Front) 25 x 8-12
28 x 9-14 - Mud Pro
Tire Size (Rear) 25 x 10-12
28 x 9-14 - Mud Pro
Tire Inflation Pressure 0.35 kg/cm² (5.0 psi)
MISCELLANY
Dry Weight (Approx) 306 kg (674 lb)
360 kg (793 lb) - Mud Pro
Gas Tank Capacity 21.6 L (5.7 U.S. gal.)
Coolant Capacity 2.9 L (3.0 U.S. qt)
Differential Capacity 275 ml (9.3 fl oz)
Rear Drive Capacity 250 ml (8.5 fl oz)
Engine Oil Capacity 1.9 L (2.0 U.S. qt)
Gasoline (Recommended) 87 Octane Regular Unleaded
Engine Oil (Recommended) Arctic Cat ACX All Weather (Synthetic)
Front Differential/Rear Drive Lubricant SAE Approved 80W-90 Hypoid
Taillight/Brakelight 12V/8W/27W
Headlight 12V/27W (4)
Starting System Electric
