D-1 TECHNICAL SPECIFICATION D-1
The arcweld
®
180i MIG Inverter Welder permissible environment:-
The surrounding temperature range:
When welding: -10 ~ +40℃
During transport or in storage: -25 ~ +55℃
Relative humidity:
At 40℃ : ≤50%
At 20℃ : ≤90%.
Avoid excessive dust, acid and corrosive materials in the air as these will damage your machine.
Excessive vibration is not permissible.
Altitude – No more than 1,000m.
500mm space about the welding machine, including from walls and other similar obstructions, is
required to enable correct flow of cooling air.
Keep protected from rain and direct sun when in use outdoors.
The wind speed for all environments should be less than 1m/s;
The Mains Input Voltage Requirement
The voltage wave form should be actual sine wave in shape with a maximum voltage variation of ±10%
of the rated value; the frequency of the voltage wave form should not exceed a variation of ± 10% of
the rated value.
The Welding Machine Configuration
The arcweld
®
180C MIG welding machines consist of:-
The upper part of the front panel is equipped with, a welding mode selector knob, a wire feed speed
knob, an output voltage control knob, an arc force control knob, a power indicator light (green),
abnormal indicator light (yellow). While the lower part is furnished with a Euro style torch quick
connector, “+” &“-” quick connectors and polarity selection. The back side is installed with power switch,
gas valve connection, cooling fan and input cable. On the top there is a handle for the convenient of
easy transport.Internally there is the primary transformer, printed circuit board, output reactor, and the
heatsink with the power semiconductors.
The package consists of:
