arcweld 180C MIG - Technical Specifications; Technical Specification Data

D-2 TECHNICAL SPECIFICATION D-2
TECHNICAL SPECIFICATIONS
INPUT – SINGLE PHASE ONLY
Machine
Standard
Voltage/Phase/
Frequency
Generator required
Maximum
Input
Current
Rated Input
Current
arcweld
®
180C MIG
220V(±10%)/ 1/50/60
Hz
>8 KVA
34A
15A
RATED OUTPUT – DC ONLY
Machine
Mode
Duty Cycle
(1)
Amperes
Volts at Rated
Amperes
arcweld
®
180C MIG
GMAW
20%
60%
100%
180A
115A
90A
23V
19.8V
18.5V
SMAW
20%
60%
100%
180A
103A
80A
25.6V
24.1V
23.2V
GTAW
30%
60%
100%
180A
129A
103A
17.2V
15.2V
14V
The duty cycle above is about 40℃.
arcweld
®
180C MIG
GMAW
40%
60%
100%
180A
140A
110A
23V
21V
19.5V
SMAW
40%
60%
100%
180A
140A
110A
27.2V
25.6V
24.4V
GTAW
40%
60%
100%
180A
140A
110A
17.2V
15.6V
14.4V
The duty cycle above is about 25℃.
OUTPUT RANGE
Machine
Mode
Open Circuit
Voltage
Welding Current
Range
Welding Voltage
Range
arcweld
®
180C MIG
GMAW
42V
30A ~ 180A
15.5V ~ 23.0V
SMAW
76V
20A~180A
20.8V ~ 27.2V
GTAW
5V
20A ~ 180A
10.8V ~ 17.2V
OTHER PARAMETERS
Machine
Power Factor
Efficiency
Protection Class
Insulation Class
arcweld
®
180C MIG
0.72
≥84%
IP21S
F
PHYSICAL DIMENSIONS
Machine
Length
Width
Height
Weight
arcweld
®
180C MIG
480mm
220mm
305mm
15Kg
(2)
