arcweld TIG 201 AC/DC - INSTALLATION; Technical Specifications

B-1 INSTALLATION B-1
TECHNICAL SPECIFICATIONS
INPUT – SINGLE PHASE
Standard Voltage / Phase / Frequency
220V (±10%) / 1 / 50/60 Hz
Rated Max. Input Power
8.1 kW (MMA mode)
7.2 kW (GTAW mode)
Recommended Fuse or Breaker Size (Super Lag or ‘D’ curve)
16A
MMA
Rated Maximum
Supply Current
34A
Max. Effective
Supply Current
15A
GTAW
30A
15A
RATED OUTPUT – DC ONLY
Welding Mode
Duty Cycle
(1)
Amperes
Volts at Rated Amperes
INPUT 1~220V
MMA
20%
60%
100%
170A
98A
76A
26.8V
23.9V
23V
GTAW
25%
60%
100%
200A
129A
100A
18V
15.2V
14V
OUTPUT RANGE
INPUT POWER
Welding Mode
Welding Current
Range
Open Circuit
Voltage
Welding Voltage Range
1~220V
MMA
10A ~ 170A
68V
13V (VRD)
20.4 V ~ 26.8V
GTAW
10A ~ 200A
10.4 V ~ 18V
OTHER PARAMETERS
Power Factor
Efficiency
Protection Class
Insulation Class
arcweld
®
TIG 201 AC/DC
0.7
80%
IP23S
F
PHYSICAL DIMENSIONS
Length
Width
Height
Weight
arcweld
®
TIG 201 AC/DC
545mm
215mm
325mm
18.0 Kg
(2)
Temperature Range
Operating Temperature Range
-10°C ~ +40°C(14°F~104°F)
Storage Temperature Range
-25°C ~ +55°C(-13°F~131°F)
(1) Based upon 10 minute time period (i.e., for 60% duty cycle, it is 6 minutes on and 4 minutes off)
(2) Power Source only.
Note: The above parameters are subject to change with the improvement of machines.
