1 - 43
1-2. Major Component Specifications
(B) Outdoor Units
AES100PIC
MODEL No.
Source
Controller P.C.B. Ass'y
Control circuit fuse
Compressor
Model…..number
Source
Nominal output W
Compressor oil cc
Coil resistance Ω C – R : 0.665 R – S : 0.665
(Ambient temperature 25°C) C – S : 0.665
Safety control
Overload relay models
Operating temperature Open °C
Close °C
Crank case heater
Refrigerant amount at shipment kg
High pressure switch
Fan
Number…diameter mm
Air circulation (Hi)
m
3
/h
Fan speeds (Max.)
Fan motor
Model No.
Source
No. of pole
Nominal output W
Coil resistance Ω RED – WHT : 30.5 WHT – BLU : 30.5
(Ambient temperature 20°C) BLU – RED : 30.5
Safety device
Operating temperature Open °C
Close °C
Run capacitor VAC, µF
Heat exchange
Coil
Rows…..fin pitch mm
Face area
m
2
AES100PIC
CR-CR254GVH56 (Microprocessor)
220 - 230 - 240 V / 1 phase / 50/60 Hz
250 V, 25 A
–
–
650
C-7RVN153H0V
126 V (DC) / 3 phase / 60 Hz (Inverter drive)
1,500
kg/cm
2
–
–
Discharge temperature control
R410A - 2.8
Set pressure OFF
–
ON
1…..ø460
90
kg/cm
2
Propeller
DAJ12-95A61A
8
3,300
~830 rpm (Inverter drive control)
~280 V / 3 phase
–
–
–
Aluminium plate fin / Copper tube
2…..1.8
0.675
04-163 Sanyo-1_p62-95 7/9/04 8:09 PM Page 84
