Argo AWS36PH - Concealed-Duct Type

1
1 - 47
1-3. Other Component Specifications
Concealed-Duct Type ADS71 - 125PH
MODEL No. Indoor Unit
Power Transformer
Rated
Primary VAC, Hz
Secondary
Coil resistance Ω
Thermal cut off temperature °C
Thermistor (Coil sensor) : TH
Resistance KΩ –10°C : 23.7 ± 5 % , 20°C : 6.5 ± 5 %
– 5°C : 18.8 ± 5 % , 30°C : 4.4 ± 5 %
0°C : 15.0 ± 5 % , 40°C : 3.1 ± 5 %
5°C : 12.1 ± 5 % , 45°C : 2.6 ± 5 %
10°C : 9.7 ± 5 % , 50°C : 2.1 ± 5 %
Thermistor (Room sensor) :
Resistance KΩ 0°C : 16.5 ± 5 % , 40°C : 2.7 ± 5 %
5°C : 12.8 ± 5 % , 45°C : 2.2 ± 5 %
10°C : 10.0 ± 5 % , 50°C : 1.8 ± 5 %
20°C : 6.3 ± 5 % , 55°C : 1.5 ± 5 %
30°C : 4.0 ± 5 % ,
Electronic expansion valve
Valve body
Coil
Drain Pump
Rated
Float switch
Rated (Contact rated)
ADS71 - 125PH
–
–
–
ADP-1413
AC230 V°C 12 W
FS-0218-102
