1-3. Other Component Specifications

Ceiling-Mounted Type ACS71 - 125PH

MODEL No. Indoor Unit

Power Transformer

Rated

Primary VAC, Hz

Secondary

Coil resistance Ω

Thermal cut off temperature °C

Thermistor (Coil sensor) : TH

Resistance KΩ –10°C : 23.7 ± 5 % , 20°C : 6.5 ± 5 %

– 5°C : 18.8 ± 5 % , 30°C : 4.4 ± 5 %

0°C : 15.0 ± 5 % , 40°C : 3.1 ± 5 %

5°C : 12.1 ± 5 % , 45°C : 2.6 ± 5 %

10°C : 9.7 ± 5 % , 50°C : 2.1 ± 5 %

Thermistor (Room sensor) :

Resistance KΩ 0°C : 16.5 ± 5 % , 40°C : 2.7 ± 5 %

5°C : 12.8 ± 5 % , 45°C : 2.2 ± 5 %

10°C : 10.0 ± 5 % , 50°C : 1.8 ± 5 %

20°C : 6.3 ± 5 % , 55°C : 1.5 ± 5 %

30°C : 4.0 ± 5 % ,

Electronic expansion valve

Valve body

Coil

Drain Pump

Rated

Float switch

Rated (Contact rated)

ACS71 - 125PH

–

FS-0218-102
