1-4. Dimensional Data
(A) Indoor Unit: Concealed-Duct Type
Refrigerant liquid line ø9.52 (narrow tube)
Refrigerant gas line ø15.88 (wide tube)
Upper drain port (O.D. 32 mm)
Bottom drain port (O.D. 32 mm)
Suspension lug
Power supply outlet (2-ø30)
Fresh air intake port (ø150)
Flange for the flexible air outlet duct (ø200)
Tube cover
Electrical component box
Flange for the air intake duct
(Option or field suppl
y
)
9
10
11
(Suspension bolt pitch)
18-ø3.3
(Hole)
1442 (Air outlet duct flange)
230 P
×
6 = 1380
1480
1560 (Suspension bolt pitch)
(150)
40
335 335 335 310 75
65
90
230
3131
185
580
25
115
19
Inspection access
(450 × 450)
(Field supply)
285
70 130
25 210
310
25
175
35
190
85
25
7030
160
630
25
10
24
260
(Air outlet
duct flange)
11
10
100, 125 Type
