Argo ODIN PLUS Service Manual

3
2. Product& Accessories Picture
2-1. Product and Accessories Pictures
2-2.Accessories:
3.Function Operation
3-1. Operation Range (cooling and heating）
Item
Front panel review
Rear panel
review
Top review
ODIN PLUS
Pictures Part Name Sizes/cm
Connector to the unit
Max. Thickness:φ155.5mm
ABS/427C/44g
Connector to the slide bar
W:237*D:137mm
Outer diameter φ155mm
thickness φ151±0.3mm
Exhaust hose
Right Rotate;
Extended sizes is:
φ150*1500mm
Compressed length :265mm
PVC Water pipe
Outer diameterφ18mm
thickness 1.8mm
Remote control
LCD:L139*W460*D200mm
Type
Temperature
Ambient Maxi.
35℃
Ambient Mini.
7℃

Argo ODIN PLUS Specifications

General

Brand	Argo
Model	ODIN PLUS
Category	Air Conditioner
Language	English
