1.5.7 Removing the overheat thermostat

1. Disconnect the overheat thermostat electrical

connections “J1” (FIG. 1.48);

2. Then remove the thermostat from its mounting by

releasing the securing clip (FIG. 1.49 /1.50).

1.5.8 Removing the heating temperature sensor

(N.T.C.)

1. Pull off the electrical connector and unscrew the sensor

probe using a suitable spanner (FIG. 1.51).

FIG. 1.48

FIG. 1.49

1.5.9 Removing the D.H.W. temperature sensor (N.T.C.)

1. Pull off the electrical connector and unscrew the sensor

probe using a suitable spanner (FIG. 1.52).

FIG. 1.51

FIG. 1.50

FIG. 1.52
