8. Dimensions
Fig. 9
All dimensions in mm
W
eight with packaging :
24 kW : 37 kg
30 kW : 40 kg
2
96 (24 kW)
360 (30 kW)
NOTE:THE CLEARANCES STATED ABOVE ARE REQUIRED FOR SERVICING PURPOSES
440
450 mini pour entretien
Minimum space required 450mm
390 mm
I S
afety valve C/H and condensate
J H
eating flow
K D.H.W. outlet
L Gas supply
M Cold water inlet
N Heating return
