Page 24 Programming manual for RD6203
DEFAULT
OPTION PHONE DELAY
(N/Y)
ALI
(N/Y)
DESCRIPTION
WP
5
N Walktest Pass
WF
5
N Walktest Fail
BV**
N Alarm confirm activation
BW**
N Alarm confirm restore
Table 8. Overview of reporting options
To see which extensions are possible with SIA transmission, see appendix 2 on page 41.
For information on how zone numbers greater than 99 are dealt with, see the protocol options for SIA, menu
5.2.3 on page 28.
1
There are no medical zones in ACPO panels. Thus this has no function in the dialler.
2
The CD34 has technical zones from version 5.9. In earlier versions programming technical reporting
has no effect in the dialler.
3
Programming of timeslots is only possible in the CD91/92/95/148/150.
4
A manual test report is reported as ‘RX’. The associated number is the telephone number tested.
5
Only available on CD95 and CD150.
* Non ACPO option
** ACPO option (UK only)
JS reporting
JS (time schedule changed) is reported after a CE message (Closing time extended), triggered by a user
code.
Example:
Area 1 is programmed to automatically arm at 19h00. User 04 decides to extend the arming time till 20h30.
The dialler will report the following event information:
account code area 1+ CE 04 + JS 203
Note: Time is displayed to the nearest 10
minutes. The final digit is not displayed.
Example 1. Programming option 'HA' to phone nbrs 1 and 2 and option 'BC' to no phone number.
1. Go to the ‘Reporting options’ menu. Press ü
üü
ü to accept .
Reporting options
The intruder alarms are programmed to telephone numbers 1, 2,
3 and 4. If these telephone numbers are also programmed in
menu 1, this event will be reported to the programmed telephone
numbers.
123
457
789
0
ü
üü
ü
HA 1234 Delay
2. The option 'BC' found in the option list by pressing â
ââ
â until you
reach it.
123
457
789
0
â
ââ
â
BC 1234 Delay
3. Press ü
üü
ü to accept.
123
457
789
0
ü
üü
ü
BC 1234 Delay
