Programming manual for RD6203 Page 19
Central station ALI
1 1.1.4
2 1.2.4
3 1.3.4
4 1.4.4
Table 6. Quick codes of audio options
1.5 Options & data for up/download
U/D
In this section the up/download, telephone numbers, account numbers and operation limits are
programmed. The ‘Correct to line’ enable is also included in this section.
Note: A U/D telephone and account number must be programmed for the ‘Connect to line’ section.
1.5.1 First telephone number for Up/Download
U/D Teleph. Nbr. 1
After the remote PC has called the RD6203, it uses this number to telephone (call back) the PC
and establish a connection for communication. The first U/D user code may also be used to
initiate a call to this number.
1.5.2 Second telephone number for up/download
U/D Teleph. Nbr. 2
This telephone number is only initiated by the entry of the second U/D user code. (No call back).
1.5.3 Account number for up/download
U/D Acc. Nbr.
The number entered in this section may be chosen by the installing company to identify the
installation.
1.5.4 Select BELL 103 or CCITT V.21
U/D Freq. CCITT
The up/download communication frequency. There is a choice here between BELL 103 and
CCITT V.21. A change to this option also requires a change in the Transport-PC program. BELL
is programmed as standard. For the UK operation this MUST be set to CCITT.
CCITT is now known as ITU-T V.21.
1.5.5 Settings for starting up/download
U/D Init.
This section is used to select or limit the operation of up/download.
1.5.5.1 Start up/download by ringing
PC Calls Yes
This enables/disables the RD 6203 establishing a connection with a remote PC by
answering/ignoring incoming ringing on the telephone line.
1.5.5.2 Start up/download via U/D code
User Code Yes
Set this option to allow/disallow a user up/download.
1.5.5.3 Connect-to-line enable
On-line Yes
When this is set to ‘Yes’ it will enable the ‘Connect-to-line’ function located in the ‘Dialler
Menu.’ If the ‘Connect -to-line’ option is accepted, the RD6203 will attempt to establish a
connection with the PC using the first Up/download telephone number. This may also be
used when using a dummy line.
