Programming manual for RD6203 Page 7
PROGRAMMING MAP FOR THE RD62
The following programming map provides an overview of all the menus available from the RD6203
modem/dialler.
Selecting a menu item
There are two methods for selecting the different menu items:
1. Use the keypad keys to scroll through the menu items (the step-by-step method). The programming map
shows the keypad keys you should press in order to arrive at the menu items. When you arrive at the
desired item, press the accept key ü. You will then move to the next set of items.
The symbols used to represent the keys are as follows:
ü Accept X Reject ↓ Move forward ↑ Move backward
2. Use the menu item’s quick code. With this method you simply enter the number(s) shown in the menu
items’ boxes of the programming map and the display will immediately select the item for you. This
method is much quicker than scrolling through the items because you press fewer keys. Consequently, it
is also less prone to keystroke errors.
The quick code numbers do not appear on the keypad display. They are shown on the programming map
to help you locate an item.
For example:
To select the item “SIA Freq. BELL” the keystrokes required are as follows:
Using the step-by-step method: Using the quick code method:
ââââ to select PROTOCOL OPT 5 to select PROTOCOL OPT
üâ to select SIA 1 2 to select TIMECLOCK
üâââ to select SIA FREQ. BELL 4 to select SIA FREQ. BELL
Number of keystrokes:
10 3
Consequently by using the quick code method, programming is quicker and less prone to error.
The menu items are explained in the chapter “Menu Contents”. They are listed in the order of their quick
codes (as shown in the programming map).
