Programming manual for RD6203 Page 41
Appendix 2: SIA extensions and Contact ID
codes
This appendix first contains an overview of the SIA extensions which a CD panel can report. An extension is
a value that is reported at the same time as the event, and it indicates what caused the event.
Events can be caused by, for example, zones, user codes, Transport-PC, key switches, or the engineer code.
Also provided is an overview of the codes used in Contact ID.
SIA extensions
Function Code Sub-Event
Meaning
CD150/95
V6.0
CD91
V6.0
CD72
V6.0
CD34
V6.0
Alarm BA/BB/BU Zone 1 - 152 1 - 88 1 - 24 1 - 10
Alarm Confirm(ACPO) BV Zone 1 - 152 1 - 88 1 - 24 1 - 10
Exit Fault EE User 1 - 100 1 - 64 18 7
Exit Fault by Key EE User 101-252 101-188 101-124 101-110
Programmed Tamper TA/TB/TU Zone 1 - 152 1 - 88 1 - 24 1 - 10
Double Pole Tamper TA/TB/TU Zone 1 - 152 1 - 88 1 - 24 n/a
Dual Zone Tamper TA/TB/TU Zone 1 - 152 1 - 88 1 - 24 1 - 10
Cabinet Tamper TA/TB/TU System 0 0 0 0
Remote Lid Tampers TA/TB/TU System 0 0 0 0
Input Expander Fault TA/TB/TU System 0 0 0 0
Duress HA/HR User 1 - 100 1 - 64 1 - 16 9
Panic Alarm Zone PA Zone 1 - 152 1 - 88 1 - 24 1 - 10
Keypad PA PA System 0 0 0 0
Fire Alarm FA/FB/FU Zone 1 - 152 1 - 88 1 - 24 1 - 10
Medical Alarm MA Zone 1 - 152 1 - 88 1 - 24 n/a
Technical Alarm ZA/ZR Zone 1 - 152 1 - 88 1 - 24 1 - 10
Closing time extended CE User 1 - 100 1 - 64 n/a n/a
Closing Extended
Until..
JS Arm Time hh:m hh:m n/a n/a
Fail to Arm on Time OT System 0 0 n/a n/a
Open Early OK System 0 0 n/a n/a
Arm by User CF/CG/CL User 1 - 100 1 - 64 1 - 16 1 - 8
Arm by Key CF/CG/CL Zone 101-252 101-188 101-124 101-110
Arm by TPC CF/CG/CL System 0 0 0 0
Arm by timeclock CP System 0 0 n/a n/a
Arm by Action List CP List Number 1-12 1-12 n/a n/a
Cancel Alarm by User BC User 1-100,255 1-64,255 1-16,255 1-8,9,255
Cancel Alarm by Key BC Zone 101-252 101-188 101-124 101-110
Cancel Alarm by TPC BC System 0 0 0 0
Cancel by ActionList BC System 0 1-12 n/a n/a
