Arkel ARCODE 4B26A - 4 ELECTRICAL INSTALLATION; 4.1 TECHNICAL SPECIFICATIONS

ARCODE HARDWARE MANUAL
Version : 1.01
Page 13 of 18
4 ELECTRICAL INSTALLATION
4.1 TECHNICAL SPECIFICATIONS
DRIVER
Model Name
4B14A
4B17A
4B26A
Optimum Machine Power
5.5 kW(7.5HP)
7.5 kW(10HP)
11 kW(15HP)
Nom. Output Current(Inom)
14 A
17 A
26 A
Max. Output Current (< 6 s)
28 A
34 A
52 A
Brake resistor (B,P)
50Ω / 1kW
50Ω / 1kW
40Ω / 1kW
Power Input(L1,L2,L3)
AC 3 Ph., 320-420V, 50/60 Hz
Power Output (U,V,W)
AC 3 Ph., 0-400V, 0-100Hz
Included EMC filters
DC Choke
EMI/RFI Filter
Evacuation(ES1,ES2)
60-120VDC battery supply input
220VAC single phase line supply input
Controller
Supply voltage
24VDC (20-28VDC)
Power consumption
?
Encoder type
ENCI (asynchronous)
HTL ot TTL, 500 – 4096 pulse
incremental
ENCA (synchronous)
EnDat, SSI and SinCos protocols
supported absolute encoder
Serial Communication
2 CANBUS (shaft and car)
3 RS485 (2 Full-Dublex,1 Half Duplex)
Relay outputs
4 Programmable relay output(10A@250VAC, 10A@30VDC)
1 Main contactor relay output(10A@250VAC, 10A@30VDC)
Signal inputs
16 Programmable input (24VDC, 3mA sink)
Floor level magnetic switches(ML1,ML2)
Motor PTC
?
