HEATING
1
Heating Speed Dip
Switch Setting First Stage heating Speed - cfm Second Stage Heating Speed-cfm
+24% 1425 1920
+18% 1355 1830
+12% 1290 1735
+6% 1220 1645
Fauctory Default 1150 1550
-6% 1080 1460
-12% 1010 1365
-18% 945 1270
COOLING
1
Cooling Speed DIP
Switch Settings
First Stage Cooling Speed -cfm Second Stage Cooling Speed-cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 935 1073 1240 1405 1320 1540 1760 2010
Factory 850 975 1125 1275 1200 1400 1600 1825
- 765 880 1015 1150 1080 1260 1440 1640
A96DS2V090C20S BLOWER PERFORMANCE (less lter)
0 through 0.8 in. w.c. (Heating) and 0 through 1.0 in. w.c. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed Dip
Switch Setting First Stage heating Speed - cfm Second Stage Heating Speed-cfm
+24% 1520 2015
+18% 1445 1920
+12% 1370 1820
+6% 1300 1725
Fauctory Default 1225 1625
-6% 1150 1530
-12% 1080 1430
-18% 1005 1335
COOLING
1
Cooling Speed DIP
Switch Settings
First Stage Cooling Speed -cfm Second Stage Cooling Speed-cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 935 1073 1238 1403 1320 1540 1760 2008
Factory 850 975 1125 1275 1200 1400 1600 1825
- 765 878 1013 1148 1080 1260 1440 1643
A96DS2V110C20S BLOWER PERFORMANCE (less lter)
0 through 0.8 in. w.c. (Heating) and 0 through 1.0 in. w.c. (Cooling) External Static Pressure Range
1
Cooling and Heating speed are based on a combination of DIP switch setting on the furnace control. Refer to installation instructon for specic DIP
Switch settings
2
Factory default setting
NOTES: The effect of static pressure is included in air volumes shown.
First stage Cool (two stage air conditioning units only) is approximately 70% of the same second stage COOL speed position
Continous Fan Only speed approximately 50% of the selected second stage cooling speed - minimum 500cfm.
1
Cooling and Heating speed are based on a combination of DIP switch setting on the furnace control. Refer to installation instructon for specic DIP
Switch settings
2
Factory default setting
NOTES: The effect of static pressure is included in air volumes shown.
First stage Cool (two stage air conditioning units only) is approximately 70% of the same second stage COOL speed position
Continous Fan Only speed approximately 50% of the selected second stage cooling speed - minimum 500cfm.
