Armstrong Air Conditioning A96DS2V - Blower Motor Performance

507405-05Page 56 of 72 Issue 1621
HEATING
1
Heating Speed Dip
Switch Setting First Stage heating Speed - cfm Second Stage Heating Speed-cfm
+24% 900 1115
+18% 855 1060
+12% 810 1010
+6% 770 955
Fauctory Default 725 900
-6% 680 845
-12% 640 795
-18% 595 740
COOLING
1
Cooling Speed DIP
Switch Settings
First Stage Cooling Speed -cfm Second Stage Cooling Speed-cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 605 745 855 965 880 1045 1210 1375
Factory 550 675 775 875 800 950 1100 1250
- 495 610 700 790 720 855 990 1125
A96DS2V045B12S BLOWER PERFORMANCE (less lter)
0 through 0.8 in. w.c. (Heating) and 0 through 1.0 in. w.c. (Cooling) External Static Pressure Range
1
Cooling and Heating speed are based on a combination of DIP switch setting on the furnace control. Refer to installation instructon for specic DIP
Switch settings
2
Factory default setting
NOTES: The effect of static pressure is included in air volumes shown.
First stage Cool (two stage air conditioning units only) is approximately 70% of the same second stage COOL speed position
Continous Fan Only speed approximately 50% of the selected second stage cooling speed - minimum 500cfm.
HEATING
1
Heating Speed Dip
Switch Setting First Stage heating Speed - cfm Second Stage Heating Speed-cfm
+24% 1085 1580
+18% 1035 1505
+12% 980 1430
+6% 928 1350
Fauctory Default 875 1275
-6% 825 1200
-12% 770 1120
-18% 720 1045
COOLING
1
Cooling Speed DIP
Switch Settings
First Stage Cooling Speed -cfm Second Stage Cooling Speed-cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 770 935 1073 1238 1100 1320 1540 1760
Factory 700 850 975 1125 1000 1200 1400 1600
- 630 765 878 1013 900 1080 1260 1440
A96DS2V070B16S BLOWER PERFORMANCE (less lter)
0 through 0.8 in. w.c. (Heating) and 0 through 1.0 in. w.c. (Cooling) External Static Pressure Range
1
Cooling and Heating speed are based on a combination of DIP switch setting on the furnace control. Refer to installation instructon for specic DIP
Switch settings
2
Factory default setting
NOTES: The effect of static pressure is included in air volumes shown.
First stage Cool (two stage air conditioning units only) is approximately 70% of the same second stage COOL speed position
Continous Fan Only speed approximately 50% of the selected second stage cooling speed - minimum 500cfm.
