Armstrong Emech G12 User Manual

Technical Data
Electrical Data
Power Supply Requirement 24 Vdc Regulated Supply ± 10% (at the actuator terminals)
Fuse 5.0 A Mini Blade (see below for Part Number)
Control Signal (input) 4 to 20mA
Feedback Signal (output) 4 to 20mA Feedback Accuracy 0.5% (of full range)
Display (Set & Actual Value) 3.5 digit 7 segment LCD and back light
Indicators 4 LEDS to indicate control mode and units
Serial Interface RS232 (non-isolated), 4pin M8 (female) connector
Auxiliary Sensor Input 4 pin M8 (male) connector
Supply and Signal Connections 9 pole screw terminal in sealed compartment
Temperature Sensor Input 3 pin M8 (female) connector
Temperature Sensor Themistor (NTC 10kOhm @ 25°C)
Cable Gland Entry 1/2” NPT ( side entry, 1 on each side)
Power Supply Consumption (at 24.0 Vdc) Motor Current Supply Supply
Model Software Setting * Current Power
G12 @I
motor
=3A 3.4 A
max
85 Watt
G13 @I
motor
=4A 4.4 A
max
115 Watt
* Exceeding motor current and speed defaults will increase current and power
Notes: (1) Nominal Torque is the output torque at 6 rpm for G12 and 5 rpm for G13.
Maximum Speed is the maximum recommended operating speed.
See G1 Torque Speed Performance data for details (page 6).
(2) These components are supplied with every actuator.
Electronic Actuator Model Code
Model Nominal Torque
(1)
Maximum Speed (RPM)
(1)
Supply Voltage
G12 035 - 35 Nm / 310 in.lb @ 6 rpm 12 24D - 24VDC
G13 100 - 100 Nm / 885 in.lb @ 5 rpm 8 24D - 24VDC
Standard Models Available G12
G13
Accessory Parts Part Number
Operating / Installation Manual
(2)
CPAC0002
Serial Cable
(2)
CPEL0091
Temperature Probes (cable length) CPAC0021 (350 mm)
Longer cable length Temperature Probes
available . Consult Armstrong
Mounting Kit F05 used on 3/4” (20 mm) and CPMA0070
1” (25 mm) Emech valves
Mounting Kit F07 used on 1-1/2” (40 mm) , 2” (50 mm), and CPMA0071
3” (75 mm) Emech valves
G13 Power Supply D34095 (24vDC 5A for G13 actuator)
G12 Power Supply D34094 (24vDC 3.5A for G12 actuator)
Mini Blade Fuse 5 A MEFU0006
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone (269) 279-3602 Toll Free (888) HOT-HOSE (468-4673)
9
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
