Connect and secure the 8 pin plug to the back of
the Electronics Module.
Important! Do not t the 4 pin plug at this
stage. To prevent a back EMF the system must
be ooded with water before the 4 pin plug is
tted.
Grounding is required, connect the power cable
to the primary power supply via switched circuit
breaker with a 3 Amp fuse or a 15 Amp grounding-
type receptacle (socket).
Do not t or replace a power cable plug!
Commission the DRV80 and recirculation system using the following instructions...
6
7
5
Power Cable

Armstrong The Brain DRV80 Specifications

General

Brand	Armstrong
Model	The Brain DRV80
Category	Control Unit
Language	English
