Setpoints - Explained
Example 1
The setpoint is the required outlet water temperature. The values in the Setpoints tab control the range in which
the setpoint can be adjusted to, but not the current setpoint itself. The Default value is the temperature the DRV
will return to should the power be lost and the DRV80 is reset. The Default is adjustable, but cannot be more than
the Max. (maximum) value or less than the Min. (minimum) value.
Temp 108˚F
Temp 108˚F
normal operation
reset after power failure
(to change back to 110°F use Adjusted Setpoint)
