44
Armstrong International
221 Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Ph. (269) 279-3602 Toll Free (888) 468-4673 Fax (269) 279-3130
PCB Connections
Motor
Battery
CN3
DB9 / RS485
DRV80 Thermistors
Power
Supply
Fuse
Relay
Fuse
Power Supply
(high voltage)
Relay
Remote Thermistors
* See separate guide - www.armstronginternational.com/sites/default/les/resources/documents/IOM-690.pdf
**See separate guide - www.armstronginternational.com/sites/default/les/resources/documents/IOM-776.pdf
CN2
SAGE
®
BS* / Modbus**
