ARRI 535B - Page 2

Genlock in
Data in
IVS Off / On / keyboard locked
Mini Monitor connector
(“normal video” or “video with data”)
”Normal video” composite out or Y-out
(“normal video” or “video with data”)
“Video with data” composite out or C-out
(“normal video” or “video with data”)
Adjustment wheel for iris IVS lens
RS connector
