46
SUB MENU
> FORMAT 1
POSITION
EDGE 1
WHITE
LEVEL 3
OUTSIDE FULL
EXIT
6.3.1 Activate Format Markings
It is possible to have no format marking (OFF),
format marking number one (1),
format marking number two (2)
or both format markings at the same time (1 & 2)
on display.
If the electronic format markings are not parallel to the
ground glass format markings, readjust the CCD chip
with the alignment screws on the CCD Optic Module
(chapter 5.3).
• Move the cursor > with the keys ß and ü to the line
FORMAT. Pressing the key ä will switch from
OFF to 1 to 2 to 1 & 2 and back to OFF, the
key ö will switch in the opposite direction.
Note: Pressing the key ENTER INSERT for more than
three seconds will cause the system to exit the
onscreen programming mode completely,
regardless of which menu is activated, with the
exception of the positioning mode.
