14 Motor layout
Soft buttons
Two soft buttons are located below the display. They change their behavior
depending on the screen content.
Menu navigation
Use the soft buttons to enter the setup menus as follows:
Menu Buttons Press button...
Motor axis (FIZ) Upper button short
Motor calibration Upper button long (3 sec)
Flip screen Upper button short (in menu "System info")
Region settings Lower button 6 sec
RF channel Lower button short
System info Lower button long (3 sec)
Note: Main screen turns off after 3 seconds.
5.2 Setup
Motor assignment
Push the upper button short to assign motor to focus, iris or zoom control.
Make sure that the assignment matches the lens axis the motor is attached
to.
Motor calibration
Hold the upper button for three seconds to start the automatic calibration of
the motor.
Press the upper button momentarily to interrupt the calibration process.
