Introduction
11
Properties
Focus knob
The TRUE BLUE
®
style focus knobs provide precise adjust-
ment and rapid flood-to-spot with only three turns. Knobs on
both sides of the fixture ensure easy access from all positions.
Sliding stirrup
The sliding stirrup design enables precise compensation for
front end accessories.
Yoke
With an extreme slim profile, the extruded aluminum yoke pro-
vides high strength without added weight. An optional, pole op-
erated yoke allows full operation of pan and tilt from the floor
and is therefore a popular choice for many studios.
Tilt-lock
The high strength tilt-lock provides extreme secure locking. It
eliminates movement and slippage and ensures that the fix-
tures will stay where you put them.
DMX-control
All functions of the ARRI L5 are controllable through DMX. The
ARRI L5 is also fully RDM compatible and is equipped with a
feedback channel for reporting all set parameters including
system status.
Fixture menu
For location applications the ARRI L5 is equipped with a fixture
menu for manual adjustment of intensity, color temperature
and plus/minus green as well as hue and saturation (functions
available depending on type).
Unpacking
The ARRI L5 is supplied with:
• Power cable with power plug or bare ends
• Stirrup
• Short 28 mm spigot with 16 mm hole (mounted on
p.o. stirrups)
• Short instructions
Please refer to chapter “Accessories” on page 49 for more in-
formation about optional accessories.
