Fixture menu
23
• Press the + / [up] or - / [down] button to select the DMX mode.
Confirm the selected mode with the ENTER button. The DMX
mode blinks three times for confirmation.
• Press the FUNCT button to leave the menu.
To set the display illumination and status indicators
To switch the display illumination and status indicators on or
off:
• Press the + / [up] or - / [down] button, until SETUP is displayed
left in the display.
• Confirm with the ENTER button. Press the + / [up] or - / [down]
button until INDC is displayed.
• Confirm with the ENTER button. The current setting is
displayed.
• Press the + / [up] or - / [down] button to select the option ON
or OFF. Confirm the selected mode with the ENTER button.
• Press the FUNCT button to leave the menu.
To read out fixture information
To display fixture information:
Operating hours
• Press the + / [up] or - / [down] button, until STATUS is dis-
played left in the display.
• Confirm with the ENTER button. Press the + / [up] or - / [down]
button until HOUR is displayed.
• Confirm with the ENTER button. The current operating
hours are displayed (e.g. 501h).
• Press the FUNCT button to leave the menu.
Version of the DMX protocol
To display the version of the DMX protocol:
• Press the + / [up] or - / [down] button, until STATUS is dis-
played left in the display.
• Confirm with the ENTER button. Press the + / [up] or - / [down]
button until DMXV is displayed.
• Confirm with the ENTER button. The current version is
displayed (e.g. 3.1).
• Press the FUNCT button to leave the menu.
Firmware-version
To display the firmware-version:
• Press the + / [up] or - / [down] button, until STATUS is dis-
played left in the display.
• Confirm with the ENTER button. Press the + / [up] or - / [down]
button until SW is displayed.
• Confirm with the ENTER button. The current firmware
version is displayed (e.g. 2.0).
