ARRI L5 - DMX Protocol (ARRI L5-DT)

DMX protocol
38
ARRI L5-DT (Daylight Tuneable)
From firmware-version 2.0
Overview
*
= Factory default
GN saturation
The value describes the shift from the neutral point to full minus
green or full plus green in percent.
(Reference: Rosco Cinegel #3304 and #3308)
Mode 1: 8 bit resolution per function
8 bit, 1 channel
per function
16 bit, 2 channels
per function
Coarse / fine, 2 chan-
nels per function
DMX mode 1
*
DMX mode 2 DMX mode 3
Channel Value Percent Function
1
0-255 0-100
Dimmer
closed → open
2
0-255 0-100
Color temperature CCT
5.000 K → 6.500 K
3
0-10
11-20
21-119
120-145
146-244
245-255
0-4
5-8
8-46
47-57
57-96
96-100
GN saturation
neutral / no effect
full minus green
-99% → -1%
neutral / no effect
1% → 99%
full plus green
