Specifications
48
Specifications
Physical
Length (Focus in flood position) . . . . . . . . . . . . . . . 280 mm (11 in.)
Length (Focus in spot position) . . . . . . . . . . . . . 373 mm (14.7 in.)
Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220 mm (8.7 in.)
Height . . . . . . . . . . . . . . . . . . 240 mm (9.5 in., Stirrup folded down)
Latch distance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169 mm / 6.65 “
Width for accessories . . . . . . . . . . . . . . . . . . . . . . . . 168 mm / 6.6 “
Weight (manual version, w/o accessories) . . . . . . 5.1 kg (11.2 lbs.)
Weight (P.O. version, w/o accessories) . . . . . . . . 7.0 kg (15.4 lbs.)
Light source
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ARRI LED Lightengine
Typ. LED lifetime L70 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50.000 h
White light. . . . . . . . . . . . . . . . . . . 2.800 K - 10.000 K (ARRI L5-C)
. . . . . . . . . . . . . . . . . . . . . . . . . . . 2.600 K - 3.600 K (ARRI L5-TT)
. . . . . . . . . . . . . . . . . . . . . . . . . . . 5.000 K - 6.500 K (ARRI L5-DT)
Colored light . . . . . . . . . . . . .RGBW color mixing (only ARRI L5-C)
Color rendering index . . . . . . . . . . . . . . . . . . . . . . . . . typ. CRI >94
Green/Magenta saturation . . . . . . +/- 1 (full green to full magenta)
Optical path
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fresnel, focussable
Lens diameter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137 mm / 5“
Half peak angle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15° - 50°
Dynamic functions
Dimmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .electronic, 0 - 100%
Color mixing . . . . . . . . . . . . . . . . . . . . . . . . . . . RGBW color mixing
. . . . . . . . . . . . . . . . . . . . . . . .(Hue and saturation, only ARRI L5-C)
Control and Programming
DMX channels . . . . . 1-16 channels, depending on type and mode
Setting and addressing. . . . . . . . . . . . . . . . Fixture menu and RDM
DMX compliance . . . . . . . . . . . . . . . . . . . . . . . . .ESTA DMX 512A
RDM compliance . . . . . . . . . . . . . . . . . . . . . . . . .ESTA DMX 512A
Firmware update. . . . . . . . . . . . . . .USB interface and LS manager
Construction
Color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Blue/silver or black
Housing . . . . . . . . . . . . . Composite housing with aluminum frame
Protection rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IP 20
Installation
Mounting. . short 28 mm (1.1 in.) spigot with 16 mm (0.63 in.) hole
Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +/- 90°
Minimum clearance around fixture . . . . . . . . . . . . . 0,5 m (19.7 in.)
Minimum view distance to light aperture . . . . . . . . 0,5 m (19.7 in.)
Connections
AC power input . . . . . . . . . . . . . . . . . Neutrik® PowerCON® True1
Battery power input. . . . . . . . . . . . . . . 4-pin locking XLR connector
DMX and RDM data in/out . . . . . . . . 5-pin, locking XLR connector
USB connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Mini-USB-A
