ARRI L5 - L5-C DMX Modes (RGBW 16-bit); L5-C DMX Modes (HSI 16-bit)

DMX protocol
44
Mode 9: RGBW, 16 bit resolution per function Mode 10: HSI, 16 bit resolution per function
Channel Value Percent Function
1HI
0-65535 0-100
Dimmer
closed → open
2LO
3HI
0-65.535 0-100
Intensity red
0% → 100%
4LO
5HI
0-65.535 0-100
Intensity green
0% → 100%
6LO
7HI
0-65.535 0-100
Intensity blue
0% → 100%
8LO
9HI
0-65.535 0-100
Intensity white
0% → 100%
10 LO
Channel Value Percent Function
1HI
0-65535 0-100
Dimmer
closed → open
2LO
3HI
0-65.535 0-100
Hue
0° → 360°
4LO
5HI
0-65.535 0-100
Saturation
0 → full saturated
6LO
