ARRI L5 - L5-C DMX Modes (HSI Coarse;fine); L5-C DMX Modes (RGBW Coarse;fine)

DMX protocol
46
Mode 13: White & HSI, Coarse / fine channel per function Mode 14: RGBW, Coarse / fine channel per function
Channel Value Percent Function
1
0-255 0-100
Dimmer coarse
closed → open
2 0-255 0-100 Dimmer fine
3
0-255 0-100
Color temperature
coarse
2.800 K → 10.000 K
4 0-255 0-100 Color temperature fine
5
0-10
11-20
21-119
120-145
146-244
245-255
0-4
5-8
8-46
47-57
57-96
96-100
GN saturation
neutral / no effect
full minus green
-99% → -1%
neutral / no effect
1% → 99%
full plus green
6
0-255 0-100
Xfade to color
White → RGBW color
7
0-255 0-100
Hue coarse
0 → 360°
8 0-255 0-100 Hue fine
9
0-255 0-100
Saturation coarse
0 → full saturated
10 0-255 0-100 Saturation fine
Channel Value Percent Function
1
0-255 0-100
Dimmer coarse
closed → open
2 0-255 0-100 Dimmer fine
3
0-255 0-100
Intensity red coarse
0% → 100%
4 0-255 0-100 Red fine
5
0-255 0-100
Intensity green coarse
0% → 100%
6 0-255 0-100 Green fine
7
0-255 0-100
Intensity blue coarse
0% → 100%
8 0-255 0-100 Blue fine
9
0-255 0-100
Intensity white coarse
0% → 100%
10 0-255 0-100 White fine
