Note: If you are connecting to a computer, use the Ethernet cable included
in the Telephony Modem package.
Making USB Connections
5 (Telephony Modems with USB ports only) Connect one end of the blue USB
cable to the blue USB port on the computer, and the other end to the blue
USB port on the back of the Telephony Modem (E).
Your computer should detect the Telephony Modem and begin installing the
drivers. See Installing USB Drivers on Your PC
for driver installation details.
Making Telephone Connections
6 Connect one end of the telephone cable to one of the grey telephone ports
on the back of the Telephony Modem (A or B). Connect the other end to the
telephone.
Note: If you have a phone with two separate lines on a single RJ-14 cord,
plug it into the port labeled “Tel 1/2”.
Touchstone TM722 Telephony Modem User’s Guide
Safety
Getting
Started
Battery
Installation Installation
USB
Drivers
Ethernet
Configuration Usage Troubleshooting Glossary
